SUKR1 TYPE
1 year sparepart warranty
3 Year Compressor Warranty
3D Air Flow
Filtering particle, bacteria and fungi
Anti-rust indoor and outdoor
Cooling faster and more efficiency of power energy consumption
Attractive design with LED Display
Use R410A refrigerant which more friendly to the environment

ASW-05A4/SUKR1

- BTU : 5000
- EER(BTU/h/w) : 10.0
- Rated Power Consumption : 500W
- Rated Running Current : 2.3A
- Power Supply Source : 220V/50 Hz
- Refrigerant : R410a
- Refrigerant Charged : 360 g
- Air Flow Volume : 410 m³/h
- Noise Level
    Indoor: 38 dB(A)
    Outdoor: 48 dB(A)
- Net Weight
    Indoor: 7 Kg
    Outdoor: 20 Kg
- Net Dimension (mm)(W x D x H)
    Indoor: 802 x 190 x 265
    Outdoor: 663 x 254 x 421
- Packing Dimension (mm)(W x D x H)
    Indoor: 860 x 255 x 325
    Outdoor: 770 x 338 x 478

ASW-09A4/SUKR1

- BTU : 9000
- EER(BTU/h/w) : 9.6
- Rated Power Consumption : 940W
- Rated Running Current : 4.3A
- Power Supply Source : 220V/50 Hz
- Refrigerant : R410a
- Refrigerant Charged : 550 g
- Air Flow Volume : 440 m³/h
- Noise Level
    Indoor: 38 dB(A)
    Outdoor: 49 dB(A)
- Net Weight
    Indoor: 7 Kg
    Outdoor: 24 Kg
- Net Dimension (mm)(W x D x H)
    Indoor: 802 x 190 x 265
    Outdoor: 700 x 231 x 489
- Packing Dimension (mm)(W x D x H)
    Indoor: 860 x 255 x 325
    Outdoor: 835 x 335 x 545

ASW-12A4/SUKR1

- BTU : 12000
- EER(BTU/h/w) : 9.6
- Rated Power Consumption : 1250W
- Rated Running Current : 5.8A
- Power Supply Source : 220V/50 Hz
- Refrigerant : R410a
- Refrigerant Charged : 900 g
- Air Flow Volume : 650 m³/h
- Noise Level
    Indoor: 43 dB(A)
    Outdoor: 53 dB(A)
- Net Weight
    Indoor: 9.5 Kg
    Outdoor: 28 Kg
- Net Dimension (mm)(W x D x H)
    Indoor: 880 x 203 x 286
    Outdoor: 760 x 260 x 540
- Packing Dimension (mm)(W x D x H)
    Indoor: 935 x 270 x 350
    Outdoor: 880 x 370 x 600

ASW-18A4/SUKR1

- BTU : 18000
- EER(BTU/h/w) : 10.8
- Rated Power Consumption : 1880W
- Rated Running Current : 8.5A
- Power Supply Source : 220V/50 Hz
- Refrigerant : R410a
- Refrigerant Charged : 1430 g
- Air Flow Volume : 850 m³/h
- Noise Level
    Indoor: 47 dB(A)
    Outdoor: 57 dB(A)
- Net Weight
    Indoor: 11 Kg
    Outdoor: 42 Kg
- Net Dimension (mm)(W x D x H)
    Indoor: 940 x 232 x 300
    Outdoor: 800 x 300 x 590
- Packing Dimension (mm)(W x D x H)
    Indoor: 993 x 285 x 360
    Outdoor: 940 x 420 x 750

ASW-24A4/SUKR1

- BTU : 24000
- EER(BTU/h/w) : 11.8
- Rated Power Consumption : 2037W
- Rated Running Current : 9.2A
- Power Supply Source : 220V/50 Hz
- Refrigerant : R410a
- Refrigerant Charged : 1650 g
- Air Flow Volume : 1100 m³/h
- Noise Level
    Indoor: 49 dB(A)
    Outdoor: 59 dB(A)
- Net Weight
    Indoor: 17 Kg
    Outdoor: 52 Kg
- Net Dimension (mm)(W x D x H)
    Indoor: 1080 x 220 x 300
    Outdoor: 800 x 300 x 690
- Packing Dimension (mm)(W x D x H)
    Indoor: 1136 x 285 x 360
    Outdoor: 940 x 420 x 750
